CH245/CH255 Motormaße
Gas Cap
Removal
12.50
(0.492)
358.46
(14.113)
65.05
(2.561)
32.53
(1.281)
M10 OIL DRAIN PLUG
113.79
(4.480)
342.71
(13.492)
17 690 08 Rev. D
88.30
(3.476)
32.53
(1.281)
65.05
(2.561)
66.0
(2.598)
162.0
(6.378)
243.55
(9.589)
KohlerEngines.com
317.62
(12.505)
29.70
(1.169)
106.00
(4.173)
METRIC FLANGE:
M8 X 1.25-6H THRU
SAE A FLANGE:
5/16-24 UNF-2B
METRIC FLANGE:
4X M8 X 1.25-6H 15
SAE A FLANGE:
4X 5/16-24 UNF-2B 15
2.96
(0.116)
307.84
(12.120)
4.50
(0.177)
40.16
(1.581)
35.97
(1.416)

Technische Daten

Maße in Millimetern.
Entspr. Zollmaße in [ ].
THRU
AIR CLEANER
COVER REMOVAL
2X Ø 10.00 (0.394)
2X Ø 10.00 (0.394) X
15.00 (0.610) SLOT
CYLINDER CENTER LINE
80.25
(3.159)
80.0
(3.150)
