- Read the internal distance d1 from the body on the rule.
- Modify the value on the right display by pressing the
previously read distance d1.
- Press the
to the outer side (the distance LED lights up on the panel).
- Position the end of the measuring arm on the plane chosen for the application of the
outer weight, as previously described for the inner side.
- Read the distance d2 from the body on the rule.
- Modify the value on the right display by pressing the
previously measured distance d2.
- Press the
- Read the rated rim diameter value on the tyre.
- Modify the value displayed on the right display by pressing the
to get the previously measured nominal diameter.
- Press to display the unbalance values (recalculated according to the new dimensions)
or perform a wheel spin.
ALU 1P
90
key again to prepare the machine for entry of the d2 distance relating
key again to set the machine for entering the nominal wheel diameter.
