General Electrical Installation Diagram - Corghi EM 9250 CompactLine Betriebsanleitung

AP1 Feeder board
AP2 Main card (CPU)
AP5 Search card
BP1 Internal pick-up
BP2 External pick-up
FU1 Fuse
FU2 Fuse
M1 Motor
QS1 Main switch
RP3 Outer distance potentiometer
JP Jumper
XS1 Power supply socket
BR2 Diameter measuring sensor
BR3 Distance measuring sensor
BR5 LASER indicator
AP22 LED light
EM 9250 CompactLine Operator's manual
ELECTRICAL SYSTEM
GENERAL DIAGRAM
UK
123
