Confirm by pressing OK and immediately the display will show:
Press the UP/DOWN buttons to select the desired hysteresis (the variation in degrees for the temperature in the specific
boiler).
Confirm by pressing OK key and immediately the display will show:
Press the UP/DOWN buttons to select the desired hysteresis (the variation in degrees for the temperature in the specific
boiler).
- If "PID" is selected, press the MENU button to confirm, and the display will show:
With the UP/DOWN buttons, select the unit of measurement for temperature, in Celsius (ºC) or in Fahrenheit (ºF).
Confirm by pressing OK and immediately the display will show:
Press the UP/DOWN buttons to select the desired boiler temperature, and confirm the selection by pressing OK.
The visual display will show:
Using the UP/DOWN buttons, select the value for each constant and confirm by pressing OK. (IT IS RECOMMENDED
THAT THOSE VALUES ESTABLISHED BY THE MANUFACTURER BE MAINTAINED.)
The visual display will show:
Initial regulation temperature for the algorithm for the three constants. (It could have a value of "2ºC / Up to 20ºC" or "3ºF
/ Up to 36ºF"). (IT IS RECOMMENDED THAT THOSE VALUES ESTABLISHED BY THE MANUFACTURER BE MAINTAINED.)
Press the UP/DOWN buttons to select the desired temperature, and confirm by pressing OK.
Once this procedure is completed, press the MENU button to move on to the following option:
The display will show the 'WATER FILTER' option, to select the number of litres of water consumed before the WATER
FILTER CHANGE/REPLACEMENT ALARM activates. Press the UP/DOWN buttons to select the quantity of water in litres.
INSTALLATION AND OPERATION MANUAL
Histe. Temp.
xxxxxxx
xxxxxx: 0,5ºC | 1ºC | 2ºC
xxxxxx: 1ºF | 2ºF | 4ºF
Boiler Temperature
xxx ºC / xxxx ºF
ºC / ºF
Boiler Temperature
xxx ºC / xxxx ºF
KP KI KD
xxx xxx xxx
PID setting
Water filter
xxxxxxx
