Iberital IB7
If the LED for the selection set is flashing during the programming of the dose, it means that the volume counter is not
sending a signal to the control unit, and at the end of the dosing the dose will be zero. Programming without water. It is
recommended that the flow meters be checked.
NOTE
If your model has a Display, you can see a screen indicating that it is in the programming menu.
NOTE
If your model has a touchscreen display, then it is possible to program the dose, by directly modifying the
volume of water through the display itself.
2.3.2. Programming the electronic pre-brew (not available on all models)
The control unit has a function called 'pre-brew'. Pre-brew can be enabled or disabled. If your machine has a visual
display, it will be possible to carry out this action via an option on the display. If it does not have a display, the function
is performed in the following manner:
To enable pre-brew, switch off the machine's main switch and press the button 1 espresso on the left button pad (group
1), keep it pressed and set the main switch to position 1 or 2, either will do, and the 1 espresso LED will light up.
Release the button and set the switch to zero (OFF) and then set it in the working position (position 2).
To disable pre-brew, set the machine's main switch to zero (OFF) and press the button 1 coffee, keep it pressed and set
the main switch to position 1 or 2, either will do, and the 1 coffee LED will light up.
Release the button and set the switch to zero (OFF) and then to position 2.
78
Iberital Intenz
Non-touchscreen display.
Doses setting
Select withing 30 s
Touchscreen display.
Manual doses
programming activated.
t1(on)
