3.4. CONNECTION TO DRAIN
A drain pipe is supplied with the machine and must be connected to the drain pan, which is the element where all the
wastewater is collected during the normal operation of the machine.
A drain outlet is therefore required to be able to cleanly evacuate these wastewater.
3.5. FEED GROUP
a) Gasket: facilitates the adjustment of the filter holder in the group.
b) Showerhead: where the water is in contact with the coffee.
c) Drainage device.
d) Solenoid valve: it allows the passage of water to the unit when a button on the button pad is pressed.
The feed group is a pressed brass block in which there is a brewing chamber. When any button on the button pad is
pressed, the pump is started and the solenoid valve is ENABLED.
3.6. BOILER
a) Feed group.
b) Injector.
c) Heat exchanger.
This boiler is manufactured in copper and a heat exchanger connected to the power supply unit passes through it.
During a supply cycle, cold water is pumped to the coffee boiler through the injector. In turn, the water inside the coffee
boiler is taken to the feed group. Under rest conditions there is permanent flow of water between the feed group and the
coffee boiler, which keeps the equipment at the optimum temperature for coffee preparation.
The temperature of the heating elements within the boilers is limited by thermostats. Should the element temperature
exceed that established by the thermostat, the machine will cut the power supply. In order to connect the elements once
more, push the reset button located on the thermostat.
3.6.1. Electrical resistance
MACHINE
IBERITAL IB7
IBERITAL INTENZ
IBERITAL TANDEM
NEW IBERITAL
IBERITAL EXPRESSION PRO
114
Nº of Boilers Groups
1
1
2
3
1
1
2
3
2
1
3
2
1
3
2
2
3
Resistance
1800 W 220-240 V
1800 W 110 V
3000-3500 W 220-240 V
2400 W 110 V
5000-6000 W 220-240 V
1800 W 110-220 V
2400 W 110 V
3000-3500-3800-5000 W 220-240 V
2400 W 110 V
5000-6000 W 220-240 V
3000-3500-3800-5000 W 220-240 V
2400 W 110 V
5000-6000 W 220-240 V
3000-3500-3800-5000 W 220-240 V
2400 W 110 V
5000-6000 W 220-240 V
3000 W + 1000 W 220-240 V
3000 W + 1000 W 220-240 V
