Iberital Expression Pro Installations- Und Betriebshandbuch Seite 102

IBERITAL
- DISPLAY CONFIG: Through this menu we can edit display visualisation settings such as
language, the customised visualisation for our company, technical services, and the current
software version.
Language
Company
Tech service
Firmware
English
Français
Language:
Deutsh
...
...
Italiano
Language:
Español
Català
...
...
Korean
Language:
Chinese
Greek
Select text
Company:
Select image
Remove both
Select
*********
*********
text:
xxxxxxxxx
Select
xxxxxxxxx
text:
Looking for logo image...
USB device not detected
Error while
downloading image
Remove text
and image?
Text and image
were removed.
Name
Technical
Phone
service
number
name:
Remove both
100
Select the highlighted language to change the general display
language. As we go down the menu, new options will appear.
Select the highlighted option to change the text and/or image for
the client's company.
(Image)
Select the desired option to add technical services contact data.
Increasing or decreasing, we pass through all the characters,
in the highlighted position. On confirmation, we move on to
the next character, until the last is confirmed.
Once the text is edited, we confirm it if correct, or cancel
the new text without saving.
Having connected a USB storage device, containing an
image to load. On going into the menu, we are shown a file
search screen.
If the loading has been successful, the screen will show
the correctly loaded image.
Error message if USB device is not detected. (It must be 8
Gb or smaller).
Error message. USB device not detected, or the image name
or format cannot be read. (The image must be called "logo.
bmp" and must be 24 bits, and 180x100px or lower).
Confirmation or cancellation of elimination of customised text
and image.
Elimination process satisfactorily completed.
INSTALLATION AND OPERATION MANUAL
