2.7 Smart Switches

The motherboard has three smart switches: Power Switch, Reset Switch and Clear
CMOS Switch, allowing users to quickly turn on/off the system, reset the system or
clear the CMOS values.
Power Switch
(PWRBTN)
(see p.1 or 2, No. 28)
Reset Switch
(RSTBTN)
(see p.1 or 2, No. 29)
Clear CMOS Switch
(CLRCBTN)
(see p.1 or 2, No. 30)
+ / - Rapid OC
Buttons
(MINUS1: see p.1 or
2, No. 7)
(PLUS1: see p.1 or 2,
No. 8)
Menu Button
(MENU1: see p.1 or 2,
No. 9)
