Chipset • Intel
Memory • Dual Channel DDR3 memory technology
• 4 x DDR3 DIMM slots
• Supports DDR3 3000+(OC)/2933(OC)/2800(OC)/2400(OC)
/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered
memory
• Max. capacity of system memory: 32GB
• Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2
• Distortion-Free Slot
Expansion • 3 x PCI Express 3.0 x16 slots (PCIE1/PCIE2/PCIE4: single
Slot at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE2); triple at x8
(PCIE1) / x4 (PCIE2) / x4 (PCIE4))
• 1 x PCI Express 2.0 x16 slot (PCIE6: x4 mode)
• 2 x PCI Express 2.0 x1 slots
• 1 x mini-PCI Express slot: For WiFi + BT module
*mini-PCI Express slot is shared with PCIE5 slot
• PLX8605 embedded
• Supports AMD Quad CrossFireX
3-Way CrossFireX
• Supports NVIDIA® Quad SLI
Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
Technology, Intel® Insider
• Pixel Shader 5.0, DirectX 11.1
• Max. shared memory 1792MB
• Supports HDMI Technology with max. resolution up to 4K ×
2K (4096x2304) @ 24Hz
• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required)
• Supports HDCP function with HDMI port
• Supports Full HD 1080p Blu-ray (BD) playback with HDMI
port
manuals search engine
Z87
TM
and CrossFireX
TM
and SLI
TM 3D, Intel® Clear Video HD
TM , Intel® HD Graphics 4400/4600
Z87 OC Formula/ac / Z87 OC Formula
TM TM
, 4-Way CrossFireX ,
TM
TM
9
