5. Models
Accessories:
Solar controller
5. Models
Model:
BASIC PRO
Digital temperature differential controller for thermal solar systems (1 collector field, 1 tank), full graphic, backlit black/white display, operation via rotary/push control
and ESC button, 3 inputs for PT 1000 sensor, analogue or PWM output for high-efficiency pump, speed regulation, pre-configured hydraulics diagram, 1 Triac output,
error monitoring, manual operation option, collector safety function; commissioning/ service assistant, fixed T and Delta T regulation, tube collector function, shut-off
delay for outputs, anti-freeze, sensor monitoring, monitoring of output parameters, operating hours counter, solar yield measurement for pump control also option
without volumetric flow meter, scope of supply includes 2 PT 1000 universal temperature sensors
Pump control by means of block modulation,
PWM or 0-10 V signal
ENERGY PRO
The same as the Basic Pro solar controller but with full graphic, dimmable colour display with background lighting, 2 Triac outputs, 1 potential-free output, 6 inputs
for PT 1000 sensors, one of which is switchable as a control output and 2 additional fixed control outputs (0-10 V or PWM) for maximum three high-efficiency pumps,
flow rate measurement function, SD card reader and USB connector (for software update, loading and saving controller settings, data logging), 24 pre-configured hyd-
raulic systems, 2 collector fields and 2 tanks, solar heating system support, remote access, booster suppression, thermostat and temperature comparison function,
solar priority charging, holiday function, anti-Legionella function, bypass and charging zone controller, scope of supply includes 2x PT 1000 universal temperature
sensors and analysis software, control of secondary pump in separated systems, swimming pool heating systems
Pump control by means of block modulation, PWM- or 0-10 V signal
MAXIMAL PRO
The same as the Energy Pro solar controller, but with 4 Triac outputs, 1 potential-free output, 10 inputs for PT 1000 sensors, of which 4 are switchable for maximum
4 high-efficiency pumps (0-10 V and PWM), radiation sensor, 30 pre-configured hydraulic diagrams, 2 collector fields and 2 tanks, circulation function, scope of sup-
ply includes 4 PT 1000 universal temperature sensors and analysis software
Pump control by means of block modulation, PWM- or 0-10 V signal
Smart Box (optional for Energy Pro / Maximal Pro)
For remote access to measurement data, evaluation, analysis and system optimisation. Remote controller parameterisation, updating of controller software, visualisa-
tion of the measurement data, interface to building management system available. 4x USB 3.0, 2x USB 2.0, HDMI, Display Port (DP), Ethernet 10/100/1000 Mbps,
Wi-Fi 802.11 ac, 64 GB SSD hard drive, external radio antenna. 127x127x45 mm To connect the Smart Box, a USB cable and SD card are required for the control-
ler – these are not included in the scope of supply. External Internet access to the Smart Box requires a fixed IP address (e.g. DYNDNS), which may incur additional
costs.
Flow transmitter for solar controller (optional for Energy Pro / Maximal Pro)
Installed length 100 mm/130 mm, connection thread 3/4" male thread, operating temperature max. +130°C, nominal flow rate Qn 1.5/2.5, pulse sequence 1 pulse/
litre, incl. 1 PT100 temperature sensor
Nominal flow rate Qn 1.5
Nominal flow rate Qn 2.5 45111.73
Other types on request
28
Art-no.
45111.56
45111.76
45111.96
45111.001
45111.72
45111.73
