5. Models

Please refer to the current price list for prices.
Gravity circulation 100% excluded. Highly efficient use of energy due to omission of gravity brakes, different connection options to MAG
and auxiliary vessel!
Complete with recirculation pump (DN 25, installed length 180 mm) with connection cable, thermally separated valve unit in return line
as shut-off and control device and thermostatic control valve with position indicator; siphon with integrated permanent air vent in supply
line and connection option for an auxiliary vessel; two contact thermometers, safety group with safety valve and manometer, two flushing,
filling and draining ball valves; flow rate control and shut-off device; flow rate display with combi scale for propylene glycol mixture and
water.
Note:
The time setting for the tube collector function on the solar controller must be set to 4 min. when using the SolaVentec II in combination
with tube collectors.
Model:
For collector surfaces up to 26 m², with flow rate indicator 1-13 l/min.
with Grundfos UPM3 HYBRID 25 - 70 / PWM signal
with Grundfos UPM3 Solar 25 - 145 / PWM signal
with Wilo Yonos Para ST 25/1 - 7 / PWM signal
For collector surfaces up to 50 m², with flow rate indicator 8-30 l/min.
with Grundfos UPM3 Solar 25 - 145 / PWM signal
with Wilo Stratos Para 25/1-11 / 0 - 10V signal
with Wilo Stratos Para 25/1-11 / PWM signal
The pump manufacturer's installation and assembly instructions must be observed.
We recommend the BASIC PRO, ENERGY PRO or MAXIMAL PRO solar controller and the corresponding flow transmitter.
Art-no.
45751.184
45751.186
45751.135 WI
45751.286
45751.233 WI
45751.234 WI
