Data transfer
Data rate (over the air)
Maximum output power (EIRP):
Remote electrode
Reference number
Product service life
Frequency bandwidth
Sensitivity range
Myo Plus app
Reference number
Supported operating system
12 Appendices

12.1 Status signals

Charge level of the 757B35=* MyoEnergy Integral battery
The battery charge level can be queried at any time.
1) With the prosthesis switched on, press the charging receptacle button and hold for less than
one second.
2) The LED display on the charging receptacle provides information on the current battery
charge level (Status signals).
Charging Event
receptacle
Battery fully charged (illuminated in green)
Battery 50% charged (illuminated in yellow)
Battery drained (illuminated in orange)
Charge level of the 757B20/757B21 EnergyPack battery
The charge level is activated for a few seconds when the battery is inserted into the prosthetic
socket.
LED indicat­ Event
or
Charge level above 50% (illuminated in green)
and Charge level below 50% (flashing alternating green and orange)
Charge level below 5% (illuminated in orange)

12.2 Operating States

12.2.1 Beep signals
The following beep signals are set by default:
Beep signal
1 x long
32
Additional display
-
2178 kbps (asymmetrical)
+8.5 dBm
13E400=*, 13E401=*
5 years
80 - 500 Hz
1800x
560X18-ANDR=V* / 560X18-IOS-V*
See the information in the Apple App Store or
Google Play Store regarding compatibility with
mobile devices and versions.
Event
• Turn off product on charging receptacle
• Charging begins (charging plug connected
to charging receptacle)
