Product specifications
10 Product specifications
Product
SYMPL bridge Node
Dimensions
(W x H x D)
Weight
Power supply input
Power consumption
Operating temperature
Storage temperature
Operating / storage humidity
Protection class
Electrical safety class
Housing
Mounting
Interface specifi cations
Interfaces
Interface specifi cations
Ethernet-Port
32
Product number
AM356970031
143 x 92 x 62 mm/
5.63 x 3.6 x 2.4 in (excl. fastening clip)
250 g / 0.55 lb
24 ... 48 V DC (terminal plug)
PoE IEEE 802.3af on RJ45
Cable cross section: 0.205 – 3.31 mm
max. 8 W (incl. DMX termination)
-40 ... 70 °C */ -4 ... 158 °F *
-40 ... 70 °C / -4 ... 158 °F
0 ... 80% RH, non-condensing
IP20
SELV
Self extinguishing blend PC/ABS
UL E140692
on 35 mm DIN rail (DIN 43880)
(19-inch rack),
any stable vertical surface
8 x DMX512 / 8 x e:pix
isolated in pairs (3.75 kV), surge protection,
reverse polarity protection
3-pin terminal plug
Cable cross section: 0.81 – 1.31 mm
V
/V
= 4.6 V/0.8 V
DMXmax
DMXmin
Short circuit protected: I
1 x e:net 10/100 Mbit/s
RJ45, surge protection
or
or
with key hole on
2
= 100 mA
SCmax
2
