General device description
2.3

User interface: LEDs

The SYMPL bridge Node has 11 LEDs on the front panel. The 11 LEDs
show the basic states of the SYMPL bridge Node.
LEDs
Status
Ethernet
Test / Error
Status +
Test / Error
DMX 1 ... 8
12
On: If constantly on, the device is online. Server
application is in operation.
Blinking: If blinking in one second intervals, the
device is offline, no connection to a SYMPHOLIGHT
server or Core is available. If blinking more rapidly,
the device is in bootloader mode.
Off: no link available.
On: link established.
Blinking: Ethernet traffic.
Off: no error detected.
Short-short-long sequence: Test mode active.
On: If constantly lights in red, an error occurred. This
can be an internal error or malfunction of the device,
or an external error, e.g. a shortcut of interface
connections or alien power supply. Switch the device
off and on. If the error persists, check the wiring or
contact OSRAM Service.
The Status and Test / Error LED blink simultaneously
to identify the SYMPL Node (enabled "Identify
Interface Mode" in SYMPHOLIGHT).
Orange: DMX data.
White: e:pix data.
Orange + White: port error.
