Output configuration
4. After configuring all ports, click the "submit" button to save the
configuration.
6.3

Source switch

The third step of the output configuration is to configure the source that
defines the switching between Source 1 and Source 2. The value of the
switch source will be taken to do a fade out / fade in between the two input
sources:
Light intensity
100 %
1. Open the source switch configuration page by selecting "Source
Switch Settings" on the left side of the web interface of the
SYMPL bridge Node:
1.
2. Select a protocol type (Art-Net, e:net, sACN, or none) from the
drop down menu. Enter the IP address of the switch source and define
the universe and channel that is to determine the switching between
26
Source 1
0 %
0 128
Source 2
DMX input
(channel value)
255
2.
3.
