Stryker IsoAir System Handbuch Seite 19

O O p p e e r r a a t t i i o o n n
W W A A R R N N I I N N G G
• Always check patient's skin regularly. Consult a physician if erythema or skin breakdown occurs. Serious injury could
result if the patient's skin condition is left untreated.
• Do not use this product with an overlay. Patient stability and siderail coverage may be compromised.
• Always consider the use of siderails. The safe use of the support surface is maximized when used in conjunction with
siderails. There may be an increased risk of falls when siderails are not present. Serious injury or death can result from
the use (potential entrapment) or non-use (potential patient falls) of siderails or other restraints. Consider local policies
regarding the use of siderails. The physician, operator, or responsible parties should determine whether and how to use
siderails based on each patient's individual needs.
• Always use extra caution with a patient at risk of a fall (such as agitated or confused) to help reduce the likelihood of a
fall.
C C A A U U T T I I O O N N - - Always be aware that an X-ray taken on this product may cause visible image artifacts. An image artifact may
interfere with patient diagnoses.
P P o o w w e e r r i i n n g g o o n n t t h h e e p p u u m m p p
To power on the pump:
1. Follow Setup the pump (page 13) to prepare the pump for operation.
2. Press and hold the P P o o w w e e r r button until I I s s o o A A i i r r appears on the screen (Figure 3).
F F i i g g u u r r e e 3 3 – – S S t t a a r r t t u u p p s s c c r r e e e e n n
N N o o t t e e - - The ALP, AST, and the LAL modes that are powered on are shown in green on the home screen (Figure 4).
T T r r a a n n s s f f e e r r r r i i n n g g a a p p a a t t i i e e n n t t f f r r o o m m o o n n e e p p a a t t i i e e n n t t s s u u p p p p o o r r t t p p l l a a t t f f o o r r m m t t o o a a n n o o t t h h e e r r
W W A A R R N N I I N N G G
• Do not use the support surface as a transfer device.
• Do not use the support surface handles to lift or move the support surface with a patient on board.
• Do not stick needles or other sharp objects into a support surface through the support surface cover. Holes may allow
fluids to enter the inside (inner core) of the support surface, product damage, or product malfunction.
• Do not exceed the safe working load of the hospital bed frame when supporting both the patient and the support surface.
Excess weight could cause unpredictable safety and performance of this product.
• Always make sure that the opposite siderail is raised when you transfer a patient onto the support surface to reduce the
risk of patient fall.
To transfer the patient from one patient support surface to another:
P P r r e e r r e e q q u u i i s s i i t t e e : : Follow hospital protocols required to transfer a patient from one surface to another.
2941-009-005 Rev A.0
IsoAir
F F i i g g u u r r e e 4 4 – – H H o o m m e e s s c c r r e e e e n n , , o o p p e e r r a a t t o o r r v v i i e e w w
15 EN
