Function
Pneumatic cushioning
Manual override
Proximity sensors
Check-choke valve
AVENTICS | ITS | R412020619–BAL–001–AD
The cylinder meets the requirements in EC Directive
94/9/EC (ATEX 95).
Characteristics and usage zones that are derived from the ATEX ID
are explained in Table 5:
Tabelle 5: ATEX ID legend
Symbol Characteristics and usage zones
II All areas, except for mining
2G Gas explosion protection, category 2G: use in zone 1
2D Dust explosion protection, category 2D: use in zone 21
3G Gas explosion protection, category 3G: use in zone 2
3D Dust explosion protection, category 3D: use in zone 22
c Constructive safety
IIB Suitable for IIB explosive areas
Typical gas: ethylene
Ignition energy: 60–180 μJ
T4 Temperature class 4
Ignition temperature of flammable material > 135°C
Max. permissible surface temperature 135°C
IP65 Protection class against dust (6) and water penetration (5)
X Special characteristics – see usage zones in the operating
instructions
Ta Ambient temperature range
5.3

Product description

Governed by the electrical valve control, the compressed air
connected to the device is directed alternately into both piston
chambers of the cylinder. The resulting dynamic effect extends
and retracts the piston rod connected to the piston.
You can adjust the pneumatic cushioning directly on the cylinder
using the throttle screws (8) inserted in both covers.
You can use the manual override (14) on the valve to switch the
valve if there is no electrical signal.
The optional proximity sensors allow the piston position to be
queried. The sensors are mounted on the tie rod (9).
With the optional CD12 series valve, you can configure a check-
choke valve that can be used to throttle exhaust air and thereby
adjust the piston speed.
