Technical Data

HYDROVAR Smart
Wall mounting unit
Panel mounting unit
The HYDROVAR-Smart is tested according to the following standards:
Ambient temperature:
Storage temperature:
Humidity:
Air pollution:
Class of protection :
Downloaded from www.Manualslib.com
Type Voltage
24 VAC/DC
24 VAC/DC
+5° C ... +40°C
-25° C ... +55° C (+70°C during max. 24 hours.)
RH max. 50% at 40°C, Unlimited
RH max. 90% at 20°C, max. 30 days per year
75% average per year (Class F, DIN 40 040)
Condensation is not permitted!
The air may contain dry dust as found in workshops where
there is no excessive quantity of dust due to machines.
Excessive amounts of dust, acids, corrosive gases, salts etc.
are not permitted
Wall mounting unit ..... IP 55
Panel mounting unit ... IP 00
manuals search engine
Supply Voltage
Max. Current
130 mA
130 mA
EN 61000-6-3
EN 61000-6-4
EN 61010-1
8
Output Signal Weight
to the Inverter kg
0 – 10 VDC 1,70
0 – 10 VDC 0,5
