b) Active MODE = Actuator:
1.
Continue by pressing the
2.
Continue by pressing the
c) Active MODE = Synch. Controller or Multicontroller:
1.
Continue by pressing the
2.
If several pumps are connected via the RS-485 interface, one pump must be ready for
operation when the set pressure is changed, otherwise the set value will not be accepted
by the follow-up pumps. Afterwards the new required pressure has to be saved in all
pumps.
If you want to change to Required Value 2 you have to close the external contact,
connected to X1/10-X1/14.
After closing this contact, the display changes from Required value 1 to
2.1
ADC-X: This parameter shows the source of the external or internal value.
XX.X Bar: shows the actual value of the Required Value 2.
Continue by pressing the
d) Active MODE = Manual control:
1.
Continue by pressing the
