INSTALLATION AND TRANSPORT
MJB4 Connections at the Rear Side for Machines with Serial Numbers > 179
1 CDA
2 OFF Air
3 Vacuum
4 Nitrogen
5 Monitor Power Supply, AC 200-240 V/ 6 A
6 External, AC200-240 V/ 6 A
7 Lamp Power Supply, AC 200-240 V/ 10 A
8 Mains Connections, AC 200-240 V
F1 - Main Power
F3 - Lamp Power Supply
F4 - Electronics
F2 - External Power/ Monitor
14
- Original Documentation -
1
3
2
4
SAFETY-INST MJB4 Rev09 17-03 INSTALLATION AND TRANSPORT
