Intended Use - Ottobock 4R101 Gebrauchsanweisung

► Instruct the user in the proper and safe use of the product.
► Please keep this document in a safe place.
1.1 Construction and Function
The 4R101 sliding adapter permits translational adjustments in the
frontal plane and the sagittal plane. The adapter consists of an upper
part and a lower part, which can be slid against each other with a
cross support. The sliding adapter is installed between the socket
attachment block and the socket adapter of a prosthesis. The low
structural height also allows use with long residual limbs.
1.2 Combination possibilities
Designation
Socket attachment block
Socket adapter

2 Intended use

2.1 Indications for use
The product is to be used solely for lower limb prosthetic fittings.
2.2 Area of application
Approved for a body weight of up to 100 kg.
The product may only be used in TF prostheses proximal to the pros­
thetic knee joint.
2.3 Environmental conditions
Storage and transport
Temperature range –20 °C to +60 °C (–4 °F to +140 °F), relative
humidity 20 % to 90 %, no mechanical vibrations or impacts
Allowable environmental conditions
Temperature range: –10 °C to +45 °C
Moisture: relative humidity: 20% to 90%, non-condensing
8
Reference number
5R1, 5R6
4R22, 4R37, 4R40, 4R51, 4R55, 4R95
Unacceptable environmental conditions
Chemicals/liquids: fresh water, salt water, perspiration, urine,
acids, soapsuds, chlorine water
Solids: dust, sand, highly hygroscopic particles (e. g. talcum)
2.4 Service life
In general, all modular adapters are tested by the manufacturer for
3 million load cycles. Depending on the user's activity level, this cor­
responds to a maximum service life of 5 years.
3 Safety
3.1 Explanation of warning symbols
Warning regarding possible risks of accident or
CAUTION
injury.
Warning regarding possible technical damage.
NOTICE
3.2 General safety instructions
CAUTION
Excessive strain on the product
Risk of injury due to breakage of load-bearing components
► Use the product according to the specified area of application
(see Page 8).
CAUTION
Unallowable combination of prosthetic components
Risk of injury due to breakage or deformation of the product
► Only combine the product with prosthetic components that are
approved for that purpose.
► Based on the instructions for use of the prosthetic components,
verify that they may be combined with each other.
