How to add terminals

The standard equipment in each apartment can be extended to a maximum of
2 telephones or 1 additional monitor, without adding power supplies.
M O N I T O R
Extension with additional telephone
Extension with additional Monitor and distributor (option 2)
Extension with additional Monitor without distributor (option 3)
* To install an additional monitor in the apartment you must use one of the 3
options shown, depending where the Monitor is placed in the last apartment
(option 1), or in a intermediate apartment (options 2 & 3).
* Any additional terminal (telephone or monitor) must be programmed once it
Pag 38
A D D I T I O N A L
T E L P H O N E
C U T
RESIST.
C U T
RESIST.
C U T
RESIST.
MAIN MONITOR
Extension with additional Monitor (option 1)
C U T
RESIST.
M A I N
MONITOR
C U T
RESIST.
M A I N
MONITOR
ADDITIONAL MONITOR
ADDITIONAL
MONITOR
ADDITIONAL
MONITOR
