3. Once the wires are connected, plug in
the connector and place the Monitor as
shown above: 1 - 2 - 3 .
Once the equipment is fully installed, the Monitor will need to be programmed
in order to assign it a call pushbutton. Follow the set up sequence shown in page
32.

OUTDOOR PANEL INSTALLATION

Follow the recommendations shown in this chapter to install the Outdoor
Panel correctly. Do not forget to remove the protective plastic film in the front of
the camera once the installation is finished.
1.Before embedding the box, break the
flange where the cables will be passed
through.
4. To unhook the Monitor, insert the screw-
driver in the notch , turn it a few degrees
and slide up the Monitor.
2.Place the embedding box at the desired
height (1.7m aprox.). Make sure that the
box is totally flush with the wall.
Pag 29
