MONITOR CONFIGURATION

Before programming, the system must be fully wired, the handset on hook and
the Monitor connected as shown below.
1. Put the jumper J1 to the
PRG position.
confirmation sound will
be heard.
Time between steps 1 and 2 must not be longer than 2 minutes. In case this
would occur, put back the jumper to its original position and restart the sequence.
OUTDOOR PANEL SET UP
The Outdoor Panel must be set up depending on the type of installation,
using the jumpers in the rear side of the amplifier.
Pag 32
2. Press the button which
A will identify the Monitor.
Once again confirmation
is generated.
A
B
C
D
JP2
3. Put back the jumper
back to its original
position and hang up the
Monitor.
* The jumper JP1 must be always
connected, except when having 2
Outdoor Panels, in which case the
jumper in one of them will be removed
(secondary).
* Select the language of the door open
message.
