THE CITYMAX MONITOR

DOOR RELEASE
push button
*
Only in installations with AUXILIARY CAMERA KIT or ADDITIONAL VIDEO PANEL
(optional).

THE OUTDOOR PANEL

AMPLIFIER
mesh
CAMERA
module
CALL
Push buttons
AUTO SWITCH-ON push button
CONTRAST control (only in B/W models)
SATURATION control (only in colour models)
ON/OFF switch
*
2 CAMERA connection
nd
STAIRS LIGHT push button (only in B/W models)
CONTRAST control (only in colour models)
BRIGHTNESS control
Volume for
OUTDOOR P ANEL
Volume for
MONITOR
CONFIGURA TION
j u mpers
Terminals for
CONNECTION
PAN & TILT
control
TEST
connector
PUSHBUTTON
connector
Pag 27
