17 Technical Information
J1 - In-Out
Tab. 3
PIN N.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

Signal Description

START/STOP: input signal to start or stop the pump. With the
supplied cover connector the START/STOP (+) signal is connected to
the +24 Vdc pin and the START/STOP (-) signal to the GROUND pin:
in this condition the pump automatically starts as soon as the
controller recognises the input supply ("Plug & Pump").
INTERLOCK: input signal to control the pump rotation. With the
supplied cover connector the INTERLOCK (+) signal is connected to
the +24 Vdc pin and the INTERLOCK (-) signal to the GROUND pin.
218/258
SIGNAL NAME
START/STOP (+)
START/STOP (-)
INTERLOCK (+)
INTERLOCK (-)
SPEED SETTING (+)
SPEED SETTING (-)
SOFT START (+)
SOFT START (-)
+24 Vdc
SPARE
PROGRAMMABLE SET POINT
SPARE
FAULT OUTPUT
PROGRAMMABLE ANALOG SIGNAL (+)
GROUND
PROGRAMMABLE ANALOG SIGNAL (-)
Special Turbo-V 1K-G User Manual / 87-901-006-01 (A)
INPUT/OUTPUT
IN
IN
IN
IN
IN
IN
IN
IN
OUT
OUT
OUT
OUT
OUT
