17
Technical Information
Vent Accessories
Figure 29
Then screw the vent valve into the pump and tighten it using a 16
mm hexagonal spanner with a torque of 2.5 Nm.
Figure 30
Do not overtighten the valve as this may damage the thread on the pump.
CAUTION!
Then connect the cable from the valve to the suitable connector on
the controller (see the preceding paragraph "INTERCONNECTIONS").
Special Turbo-V 1K-G User Manual / 87-901-006-01 (A) 243/258
