TEMPERATURE DISPLAY
Temperature Display Bars:
Cooking In Progress
Oven cavity temperature < 1/6 of set
point
Oven cavity temperature between 1/6
and 2/6 of set point
Oven cavity temperature between 2/6
and 3/6 of set point
Oven cavity temperature between 3/6
and 4/6 of set point
Oven cavity temperature between 4/6
and 5/6 of set point
Oven cavity temperature > 5/6 of set
point
Temperature Display Symbols:
Thermostatic Control (Heating Elements) Status
 Lit up = Heating Elements active
 Off = Heating Elements inactive
Temperature Set Point Status
 Lit up = Temperature Set Point not reached
yet
 Off = Temperature Set Point already
reached
ELCTRONIC TIMER USAGE:
POWER ON
Upon power up, Timer Display digits are flashing, the oven is inoperative. The selected cooking
Function (if any) is shown on the Cooking Function Display (See. Selecting a Cooking Function). The
Temperature Display shows the default Temperature assigned to this function. Turn the Navigator
Knob in any direction to return to the manual mode and activate the oven. Using the navigator, adjust
the Time of Day (See. Adjusting Time of Day).
Note: Incase of mains power failure more than 10 seconds while cooking is in progress, oven will get
inoperative, any preprogrammed timer and temperature will be cleared. Turn the Navigator Knob in
any direction to return to the manual mode and activate the oven.
Cooking Not In Progress
Oven cavity temperature < 60 °C
Oven cavity temperature between 60
°C and 100 °C
Oven cavity temperature between 100
°C and 150 °C
Oven cavity temperature between 150
°C and 200 °C
Oven cavity temperature between 200
°C and 250 °C
Oven cavity temperature > 250 °C
