THE SCREEN SYMBOLS:
User entries are made by 6 touch buttons on both sides. Background color is black.
Symbols related to the oven status are RED, active status and ready to select parameters
are WHITE, others are BLUE colored, besides also other colors for special indications.
Oven is active, cooking is possible
depending on the function selector and
temperature knob settings.
Oven is inactive.
This symbol will be flashing when power
on or upon completion of an automatic
cooking program. In case of a delayed
cooking, it will appear steady during
waiting for the start time .
Key lock
Alarm
Appears steady when any alarm is or is being
programmed, flashes when the programmed
alarm time/duration has elapsed .
Auto Cooking
Appears steady during an automatic
cooking flashes upon its completion.
Start of Cooking
Cooking Duration
End of Cooking
Cooking function recommendation (left
example is for top + bottom + fan )
Alarm Clock
THE IDLE SCREEN:
Digital Screen Clock Analog Screen Clock
20
Settings Menu
Cooking Menu
Cooking Guide Menu
Screen Clock Appearance Menu
Language Selection Menu
Time of day / clock adjustment
Menu
Date adjustment Menu
Sound Menu ( symbol on the left
means all sound effects are on )
Tray position recommendation
( left example is for the mid
position )
The idle screen is visible when no
cooking has been programmed. The
screen will show the time of day, date
and the oven status (
Besides those basic indications, the key
lock symbol if active and
or when any alarm has been set
may also appear.
or )
