ELECTRICAL CONNECTION

All electrical connections in accordance with applicable laws and rules should be done only
by a qualified electrician. Connections must comply with national regulations.
Electrıc Connectıon Device Before
Which is positioned on the front bottom of the main power is supplied from the mains

power will meet the specified record label sure.
 The appliance must be connected in accordance with the rules currently in force,
and only by an officially authorized technician. The manufacturer will not accept
responsibility for any damage to persons, animals or things due to wrong electric
connection.
 Current value of the insurance for the product must be at least 16A.
 If Current value of insurance is under 16 amperes, qualified electrical technician must
called for changing ampermeter.
 Connection must comply with national regulations.
 Grounded plug is mounted to oven energy supply cord.This must used with grounding-
line.Please make a qualified electirical grounding installation.
WARNING: This appliance must be earthed.
If your oven doesn't have a power supply cable, provide a power supply cable to your
product by qualified electrician from following features.
Voltage
220-240V AC 50 Hz
Power supply cable in;
Yellow / green, the grounding cable must be connected to the terminal.
Blue neutral wire connected to the terminal marked with the''N''.
Black, brown or red electrical cables installed must be connected to edge indicated by
the''L''. (See Figure 5)
Figure 4
Cable Type Conductor Size
H05 VV - F 3 x 1,5 mm
Table 1
8
Current (Amp)
16A
2
