VessRAID 1000f, 1000i, 1000s Series Quick Start Guide
Figure 4. VessRAID 1830s+ rear view
Dual Power Supplies
Figure 5. VessRAID 1830i rear view
Dual Power Supplies
Figure 6. VessRAID 1730s rear view
Single Power Supply
For a description of the LEDs, see pages 30 and 31.
SAS RAID Controller
External Fans
iSCSI RAID Controller
Internal Fans
SAS RAID Controller
Internal Fans
