Figure 23.SAS JBOD expansion data connections
SAS Expansion Port
VessRAID 1830i
SAS OUT Port
SAS data cable
VessJBOD 1730
SAS IN Port
VessJBOD 1830+
After you complete your data and management connection, go to "Task 6: Setting
Up Serial Cable Connections" on page 29.
