VessRAID 1000f, 1000i, 1000s Series Quick Start Guide

Task 9: Creating Logical Drives with WebPAM PROe

Setting up WebPAM PROe consists of the following actions:
• Logging into WebPAM PROe (below)
• Choosing a Language (page 41)
• Creating Your Logical Drives (page 42)
• Logging out of WebPAM PROe (page 46)
• Using WebPAM PROe over the Internet (page 46)
Logging into WebPAM PROe
1. Launch your Browser.
2. In the Browser address field, type the IP address of the VessRAID
subsystem.
Use the IP address you obtained in Task 7 (see page 36). Note that the IP
address shown below is only an example. The IP address you type into your
browser will be different.
Regular Connection
• WebPAM PROe uses an HTTP connection. . . . . . . . . . . . . . . .http://
• Enter the VessRAID's IP address . . . . . . . . . . . . . . . 192.168.10.85
Together, your entry looks like this:
http://192.168.10.85
Secure Connection
• WebPAM PROe uses a secure HTTP connection . . . . . . . . . .https://
• Enter the VessRAID's IP address . . . . . . . . . . . . . . . 192.168.10.85
Together, your entry looks like this:
https://192.168.10.85
3. When the log-in screen appears:
• Type administrator in the User Name field.
• Type password in the Password field.
• Click the Login button.
The User Name and Password are case sensitive
Whether you choose a regular or a secure connection, your login
to WebPAM PROe and your user password are always secure.
Note
40
