Figure 10.Rack mount assembly diagram
Rack front post
Inside of post
Note that only the front rail has a support for the subsystem.
This completes rack mounting. Go to "Task 4: Installing Disk Drives" on page 12.
Alignment pins
two on each flange
Rear rail
Front rail
Support for
subsystem
Rail attaching screws
(not included)
11
Task 3: Mounting VessRAID in a Rack
Rack rear post
Inside of post
