Figure 20.iSCSI SAN data and management connections
Standard
NIC
GbE NIC
Management Cables
Data Cables
VessRAID 1830i+
VessRAID 1730i
Management Port
24
Standard
NIC
GbE NIC
Host PCs or
Servers
Standard
Network
Switch
GbE
Network
Switch
iSCSI Data
Ports (4)
