Figure 18.VessRAID 1830i+ data and management ports. 1830i is similar
Management Port
Figure 19.iSCSI DAS data and management connections
Standard NIC
GbE NIC
Standard Network Switch
Data Cable
VessRAID 1830i+
1830i is similar
Task 5: Making Data and Management Connections
iSCSI Data Port 3
iSCSI Data Port 2
iSCSI Data Port 1
Management Port
21
iSCSI Data Port 4
SAS Expansion
Port (to JBOD)
Host PC
or Server
Management
Cables
iSCSI Data Ports (4)
