Additional Operations - Yamaha RX-V1500 Bedienungsanleitung

Remote control operation
+ + +
TV VOL CH VOL
– – –
A / B / C / D / E
TV MUTE TV INPUT MUTE
LEVEL SET MENU
TITLE MENU
ENTER
TEST ON SCREEN
RETURN DISPLAY
STEREO HALL JAZZ
1 2 3
ENTERTAIN MUSIC TV THTR
5 6 7
THX STANDARD EXTD. SUR
9 0 +10
Set AMP/SOURCE/TV to AMP, then press one of
the sound field program buttons repeatedly to
select the desired program.
The name of the selected program appears in the front
panel display and video monitor.
AMP
SOURCE
TV
V–AUX DVR/VCR2 VCR 1 CBL/SAT DTV
SP
A
J A Z Z C L U B
Program name
y
Choose a sound field program based on your listening preference,
and not on the name of the program.
Notes
• When you select an input source, this unit automatically selects
the last sound field program used with that source.
• Sound field programs cannot be selected when the MULTI CH
INPUT is selected.
AMP
AMP/SOURCE/TV
SOURCE
TV
PURE DIRECT
NIGHT
AUDIO
STRAIGHT
EFFECT
Sound field
ROCK
4
program
MOVIE
8
buttons
ENT.
STEREO HALL JAZZ ROCK
1 2 3 4
ENTERTAIN MUSIC TV THTR MOVIE
5 6 7 8
THX STANDARD EXTD. SUR
9 0 +10
ENT.
DVD MD/TAPE CD–R CD TUNER PHONO
HiFi DSP
dB
VOLUME
L L

Additional operations

To adjust the tone
TONE CONTROL
PROGRAM
Select BASS, then rotate PROGRAM to the right or left to
increase or decrease the low-frequency response.
To cancel the tone control, press TONE CONTROL
repeatedly to select BYPASS.
Notes
• If you increase or decrease the high-frequency or the low-
frequency sound to an extreme level, the tonal quality of the
surround speakers may not match that of the front left/right and
center speakers.
• TONE CONTROL is not effective when THX (page 49) or
PURE DIRECT (page 37) is selected, or when MULTI CH
INPUT is selected.
R
• TONE CONTROL is not effective for headphones. Use HP
TONE CTRL to adjust bass/treble balance for the headphones
(page 62).
To mute the sound
Press MUTE on the remote control.
The MUTE indicator flashes in the
front panel display.
To resume the audio output, press
MUTE again (or press VOL –/+). The MUTE indicator
disappears from the display.
y
You can adjust the muting level (see page 62).
To listen with headphones
("SILENT CINEMA")
"SILENT CINEMA" allows you to enjoy multi-channel
music or movie sound, including Dolby Digital and DTS
surround, through ordinary headphones. "SILENT
CINEMA" activates automatically whenever you connect
headphones to the PHONES jack while listening to
CINEMA DSP or HiFi DSP sound field programs. When
activated, the "SILENT CINEMA" indicator lights up in
the front panel display.
Notes
• This unit will not be set to "SILENT CINEMA" when MULTI
CH INPUT is selected as the input source.
• "SILENT CINEMA" is not effective when PURE DIRECT or a
2ch stereo program is selected, or in STRAIGHT mode.
PLAYBACK
You can adjust the bass/treble
balance for the front left/right and
center channels.
Press TONE CONTROL
repeatedly on the front panel to
select TREBLE or BASS.
Select TREBLE, then rotate
PROGRAM to the right or left to
increase or decrease the high-
frequency response.
MUTE
35
