2.1 | Connection

Front View of the Interface Box
Potentiometers
for adjustment
of the input
sensitivity of
0 dB reading
(150 mV - 30 V)
Analog In L
(RCA) *)
*) Analog In via RCA and
Analog In via Sub-D can-
not be used in parallel!
Manual | TM3S
Analog In R
(RCA) *)
S/PDIF Out
(RCA)
S/PDIF In
(RCA)
2 | Installation | 2.1 | Connection
EN
GP IO
(RJ-12-6P6C)
