2 | Installation

The TouchMonitor TM3 Smart devices are designed for free positioning
on tables, desks, et. al. A TM3S unit consist of a display unit with 4.3 inch
touch screen and a separate interfacebox featuring many capabilities of
connecting. The connected cable supplies the display unit with power and
data. Power supply for the whole unit is supplied through the +24 V DC
connector on the interfacebox. Use with power supply model ATS 065T-
P/A240, manufactured by Adapter Technology Co Ltd. (which is the
external wide voltage power supply unit RTW 1178-R, included in TM3
Smart packages). Ordered with TM3-2U option allows panel-mounting.
ATTENTION! –
• Before installing the unit please study the safety instructions and the
information on connection and pin assignment.
• An external overcurrent protective device (2 A max.) shall be installed
when using an external 24 V DC power supply!
• Make sure that the delivered power supply unit is not connected.
• Place the unit at a suited place. The display unit shall positioned secu-
rely on a fl at surface. The interface box may be placed corresponding to
the cable length away outside the sight fi eld, e. g. on the bottom behind
a table. Please take care about a good guiding of the connected cable.
• Connect unbalanced signal sources to the RCA connectors. Connect
balanced signal sources to the Sub-D connector. Connect all your
other components to the appropriate connectors. Use the correct stan-
dard connection cables for the components and take care about the
pin assignment described in paragraph 2.2!
• Finally, connect the locking 4-pin low voltage connector of the external
power supply to the +24 V DC connector of the interface box. Con-
nect the external power supply to mains.
• The TouchMonitor will initiate its system startup sequence. After the
boot-up the unit is ready for use.
EN-14 2 | Installation
Please read before installing:
Manual | TM3S
