Specifi cations (continued)
Global Keyboard
Loudness and SPL Display
EBU R128 Loudness Mode
ITU-R BS.1771 Loudness Mode
ATSC A/85 Loudness Mode
ARIB Loudness Mode
OP-59 Loudness Mode
AGCOM Loudness Mode
CALM Loudness Mode
Customer Specifi c Loudness Mode
Display:
Numerical display:
Scales: *)
Manual | TM3S
The Global Keyboard is used for control of defi ned
functions in multiple instruments, and for preset recall. It
also allows the external control with the integrated GP IO
interface.
• Bargraphs for each single channel (can be combined
with PPM bargraphs)
• M bargraph (Momentary value)
• S bargraph (Short - shortterm value)
• I-Bargraph (Integrated - long term value)
• Red scale markers for 0 LU thresholds
S, I , M, LRA, TPmax, Mmax, Smax, I time value
Loudness scales:
• EBU+9: +9 .. –18 LU
• EBU+18: +18 .. –36 LU
• EBU+9a: 14 .. –41 LUFS
