Specifi cations (continued)
Weighting fi lter:
Target Level: *)
Time & Gate Momentary: *)
- Window Time:
- Integration Time:
Time & Gate Short: *)
- Integration Time:
Time & Gate Integrated: *)
- Silence Gate:
- Relative Gate:
Level adjustment for the
summation: *)
Upper tolerance M, S, I:
Lower tolerance M, S, I:
*) Depending on the used loudness standard not all of the listed settings are available.
EN-68
7 | Specifi cations
• EBU+18a: –5 .. –59 LUFS
• EBU0: 0 .. –60 LUFS
• ITU+9: +9 .. –18 LU
• ITU0: 0 .. –30 LKFS
• ATSC0: 0 .. –60 LKFS
• ATSC0a: 0 .. –30 LKFS
K fi lter acc. to ITU-R BS.1770
–23 LUFS; adjustable from –10 to –30 LUFS/LKFS
adjustable from 200 ms to 1000 ms in steps of 100 ms
IEC 125 ms Fast, 250 ms (IRT), 500 ms, 750 ms, IEC
1000 ms Slow, 1500 ms, 2000 ms selectable
3 s; time window adjustable from 1 to 20 s in steps of 1 s
–70.0 LUFS; adjustable from –80.0 LUFS to –40.0 LUFS
in steps of 0.5 LUFS, switchable
–10.0 LU; adjustable from –40.0 LU to 0 LU in steps of
0.5 LUFS, switchable
• 0.0 dB (L, R, C), adjustable between –3 and +3 dB in
steps of 0.5 dB
• +1.5 dB (LS, RS), adjustable between –3 and +3 dB in
steps of 0.5 dB
• Off (LFE), selectable: Off, 0 dB, 10 dB
acc. to standard; tolerance above the Target Level, adjus-
table from 0 to +10 LU in steps of 0.1 LU
acc. to standard; tolerance below the Target Level, adjus-
table from 0 to –12 LU in steps of 0.1 LU
Manual | TM3S
