Specifi cations (continued)
Moving Coil
Moving Coil instrument for the display of needle instruments for up to 2-channel
Stereo with different scales.
Type:
PPM:
- Ch. arrangement:
- Scales:
- Integration time:
- Headroom Ref:
- S mode:
- Peak indicator:
- BR Peak Threshold: 6 dB,
VU:
- Ch. arrangement:
- Scale analog:
- Scale digital:
- Lead:
- Peak indicator:
Loudness:
- Ch. arrangement:
- Scales:
- Integration time:
- Peak indicator:
PPM + Loudness:
- Ch. arrangement:
- Scales:
Numerical display:
EN-70 7 | Specifi cations
PPM (L/R), PPM (M/S), VU, Loudness, PPM + Loudness
(L/R; M, S, or I), selectable
Dual, Dual + M/S horizontal, Dual + M/S vertical, Stereo
horizontal, Stereo vertical
• BR IIa: 7. .1, BR IIa ext: 7. .1
• BR IIb: +12. .–12 dB, BR IIb ext: +12. .–12 dB
Sample (digital only), 0.1 ms, 1 ms, 10 ms, 20 ms, 150 ms
available with digital sources only: –10 dB; adjustable from
0 to –20 dB in steps of 1 dB
only available, if M/S type is selected: M3, M6
Off, Peak, True Peak, BR Peak
• BR IIa: adjustable from 4 to 7 dB in steps of 1 dB
• BR IIb: adjustable from 0 to 12 dB in steps of 1 dB
Stereo horizontal, Stereo vertical
VU (–20 to +3 dB)
VU Digital (–20 to + 3 dB)
0 dB, adjustable from 0 to 12 dB in steps of 1 dB
Off, Peak, True Peak
Dual, Stereo horizontal, Stereo vertical
acc. to Loudness settings
acc. to standard
Off, no selectable option available
Dual-PPM (as described above) with additional Loudness
display for M, S, or I (selectable) in one instrument
• PPM: see above
• Loudness: +9 to –9 LU fi xed (mid of scale corresponds
to Target Level)
switchable
