Specifi cations (continued)
Loudness Test Time Control
Settings for operating automatic, semi-automatic or manual loudness measurements.
Start:
- Functions:
- Level for gate:
Stop:
- Functions:
- Level for gate:
- Time for gate:
Loudness Range Instrument (LRA)
Display:
Mode:
Scale range:
LRA low range:
Comfort zone:
LRA high range:
Colors:
SPL Meter Mode
Display:
Reference point:
Weighting:
Integration time:
Manual | TM3S
Autostart after preset load, autostart with gate, autostart
with gate and autoreset, manually via keys or GPI
–70,0 LUFS/LKFS; adjustable from –85 to –10 LUFS/
LKFS in steps of 0.5 LUFS/LKFS
manually via keys or GPI, autostop with gate, autostop with
gate and time
–70,0 LUFS/LKFS; adjustable from –85 to –10 LUFS/
LKFS in steps of 0.5 LUFS/LKFS
1 s; adjustable from 1 to 15 s in steps of 1 s
Graphical display of the Loudness Range
selectable: LRA Bar, MagicLRA, MagicLRA + I,
MagicLRA + I + Num
selectable: 6 LU, 10 LU, 20 LU, 30 LU
2 LU; adjustable from 1 to 20 LU in steps of 1 LU
4 LU; adjustable from 1 to 20 LU in steps of 1 LU
depends on the selected scale range and the spread of
the comfort zone
selectable for each range
• Bargraphs for each single channel (can be combined
with PPM bargraphs)
• Summation bargraph
adjustable from 68 dB to 88 dB in steps of 1 dB
Linear, A (Leq(A)), C, CCIR (Leq(M)), k
Fast (125 ms), Slow (1 s)
7 | Specifi cations EN-69
