The following listing describes the most important features of all factory
presets. The input connectors used by each preset are also listed. The au-
dio inputs of the TM3S devices and the pinouts of the Sub-D connector
are described in detail in chapter 2 | Installation.
NOTE - Presets with the input notation Analog are calibrated to
the indicated reference level (+6 dBu) only if using the balanced analog
inputs on the Sub-D connector. If you prefer to use the unbalanced RCA
inputs instead, please make sure that these inputs are calibrated to your
preferred reference level before using them. The unbalanced reference
level can be set using the two Unbal Ref potentiometers close to the
RCA inputs over the range of 150 mV - 30 V. As a factory default, the
RCA inputs are calibrated to a reference level of –10 dBV if a reference
level of +6 dBu for the balanced inputs is set in the preset.
The chapter 5 | Instruments contains short descriptions of the inst-
ruments used in the presets as well as some hints for a fast interpre-
tation of the readings.
