MSH Basic-FUBO-E-R3 (R2, R5) with seal insert MSH
Basic-MB-R3 (R2, R5)
10 The following instructions are to be observed prior to installation of the
MSH Basic-FUBO-E-R3 (R2, R5) and MSH Basic-MB-R3 (R2, R5):
WARNING!
Risk of injury in the event of improper installation!
Improper installation can result in signifi cant bodily harm and property damage.
• MSH Basic-FUBO-E-R3 (R2, R5) and MSH Basic-MB-R3 (R2, R5) installation must
• The nationally applicable laying and fi lling regulations for pipes and cables are
NOTE!
Failure to seal due to incorrect installation!
Improper installation can result in damage.
• Seal the underground and pipe substructure well prior to laying pipes/cables so
• A recess in the strip foundation can be planned so as to maintain the wall
• After connecting the pipes, check the bend radii R ≥ 1 m.
• The relevant country specifi c standards and regulations are to be observed when
• For details of other accessories and further information, see www�hauff-technik�de

11 Preparing for assembly

NOTE!
No sealing due to incorrect assembly!
Improper installation can result in damage.
• For precise positioning of the MSH Basic-FUBO-E
R3 (R2, R5) (basic unit), a batter board must be
prepared on site. The line should ideally mark
both the upper edge of the unfi nished fl oor and
the wall inner side (see fi g.: 1).
comply with the relevant professional association regulations, VDE provisions,
national safety and accident prevention regulations as well as company regu-
lations (work and procedural instructions).
to be observed at all times.
that the latter cannot subside.
clearance, depending on the foundation design and by agreement with the
architect or builder.
carrying out concreting work. This applies especially to concrete construction
elements according to EN206-1 which are impermeable to water.
and the technical specifi cation sheets.
Art. Nr.: 5090031112 Rev.: 01/2018-09-17
EN
Fig.: 1
