I/O Panel
1
16
15
No. Description
1
PS/2 Mouse/Keyboard Port
2
LAN RJ-45 Port (Intel® I211AT)*
3
Central / Bass (Orange)
4
Rear Speaker (Black)
5
Line In (Light Blue)
6
Front Speaker (Lime)**
7
Microphone (Pink)
8
Optical SPDIF Out Port
* There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
SPEED LED
LAN Port
Activity / Link LED
Status
Description
Off
No Link
Blinking
Data Activity
On
Link
2
14
13
12
No. Description
9
10
11
12
13
14
15
16
Speed LED
Status
Off
Orange
Green
11
9
10
USB 3.1 Gen2 Type-A Port (USB31_TA_1)
USB 3.1 Gen2 Type-C Port (USB31_TC_1)
USB 3.1 Gen1 Ports (USB3_5_6)
USB 3.1 Gen1 Ports (USB3_3_4)
HDMI Port
Clear CMOS Button
USB 3.1 Gen1 Ports (USB3_1_2)
Antenna Ports
Description
10Mbps connection
100Mbps connection
1Gbps connection
X470 Taichi
3
5
4
6
8
7
3
