Voltage range: 12-24VDC
Max. Current: 0,2A
There is the possibility, to connect the easyCPA³ as an additional
accessory. The device has predefined switches and buttons for the
above-mentioned functions. The easyCPA³ additionally has an external
signal generator for CPA alert and AIS S.A.R.T.
Based on the cable assignment under position 81 you may connect our
small external signal generator with the brown and white cable. This is
a device which is only suitable for CPA or anchor alert and AIS S.A.R.T.
Simply connect the corresponding colors.
When the CPA is connected the easyTRX2S devices send an alarm signal
to the switching output. The attached signal generator easyCPA
generates a loud and clearly audible alarm sound. This alarm sound
rings out at a CPA alert or if an AIS SART message is received.

8.6.2 Multiplexer (NMEA-Input, 38400/4800 baud)

You may connect a NMEA sensor (e.g. log, anemometer, etc.) with a
baud rate of 4800 or 38400 baud to the 6 pole cable of the pair of
conductors (brown/yellow) position 5 and 6. The sensor data is put out
to the plotter and PC together with the AIS and GPS data.
(Note: You cannot connect a GPS receiver as the easyTRX2S has its own
GPS receiver, and only these data can be interpreted and displayed at
the plotter or PC.
If you want to multiplex data from a 38400 baud device please set the
input baud rate with the programming tool.
You can find this under "static data" => "Mux-in"
8.7 DATA RECORDING – SD CARD
Also see point 6.5 on page 89
The easyTRX2S devices provide the possibility to record data onto a SD
card. All data rendered on the NMEA0183 and USB is recorded on a SD
card.
