to a transmission every minute. Our transceivers verify a „real" push of
a button to trigger a SRM transmission.)
If you want to use this function in an easy way, you can purchase the
easyCPA³ (A056) as accessory. It is a small box which includes a button
for PAN PAN and a switch for switching to "silent mode" or "anchor
alert" next to an external signal generator for CPA alert and AIS
S.A.R.T.

8.5.2 Switch (function set by software)

The default value is set to silent mode. If you want to change the
function please do this by using the programming tool.
8.5.2.1
According to the cable assignment under paragraph 5 page 81, the
brown and the yellow cable of the 4-pole cable are destined for this
functionality. If these cables are connected to a SWITCH (not a
Pushbutton) e.g. switchboard and short-circuit the cables with the
button, i.e. connect them the easyTRX2S Transceiver is set to pure
receiving mode, i.e. "silent mode".
By opening the switch the TRX2S resets to normal conditions
automatically, i.e. receiving and transmitting mode.
This function is preset by default with a switch on the easyCPA³ unit.
8.5.2.2 Anchor alarm
If you want to change the function to anchor alarm please open the
programming tool – see under paragraph 6.7. You can choose one
function. If the anchor alarm is active by set the switch to "1" and you
drive out of range of your set position the TRX2S set the output port of
CPA to high and an external buzzer e.g. easyCPA³ will switch on.

8.6 External Devices (additional)

8.6.1 Buzzer

Specification buzzer:
