OPTIONALS -
For the connections and the technical data of the fixtures follow the relevant handbooks.
EXPANDER CARD
!! FEED THE EXP CARD IN WHEN POWER IS NOT SUPPLIED !!
- PEDESTRIAN OPENING COMMAND
- AUTOMATIC PEDESTRIAN CLOSING
- MANAGEMENT OF THE SAFETY EDGE
- 24VAC ACCESSORIES FEEDING
- MANAGEMENT OF THE TRAFFIC LIGHT CONTR
- MANAGEMENT OF THE COURTESY LIGHT
- CLOSING COMMAND AFTER PASSING THROUGH THE PHOTOCELLS*
code ACG5470
RADIO TRANSMITTER SUN
SUN 2CH code ACG6052
SUN CLONE 2CH code ACG6056
CODE LEARNIG SYSTEM RADIORECEIVERS
S433 1CH 1-channel with connnector
S433 1CH 1-channel with terminal Block
S433 2CH 2-channels with connnector
S433 2CH 2-channels with terminal Block
S433 4CH 4-channels with connnector
S433 4CH 4-channels with terminal Block
D5
D4
D3
D2
SUN 4CH code ACG6054
SUN CLONE 4CH code ACG6058
code ACG5081
code ACG5082
code ACG5083
code ACG5084
code ACG5085
code ACG5086
SPARK
In order to make the systems mentioned above give the best performances, you need to
install an antenna tuned on the frequency of the radio receiver installed.
N.B. Pay attention to not let the central wire of the cable to came Into contact with
the external copper sheath, since this would prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can reach it.
SPARK BLINKER WITH IN-BUILT INTERMITTENT CARD
LATERAL SUPPORT
SPARK ANTENNA 433
FIT SYNCRO
FIT SYNCRO PHOTOCELLS for the wall-installation
The range you can set is 10-20 m, 30÷60ft.
You can fit many couples close together thanks to the synchronising circuit.
Add the SYNCRO TRANSMITTER
for more than 2 photocells couples (up to 4).
COUPLE OF BUILT-IN BOXES FOR THE FIT SYNCRO
BLOCK
KEY SELECTOR FOR WALL-INSTALLATION
KEY SELECTOR TO BUILD-IN
22
code ACG7059
code ACG7042
code ACG5452
code ACG8026
code ACG8028
code ACG8051
code ACG1053
code ACG1048
