B - OPERATING MICROSWITCH
DIP 1 CHECKING THE ROTATION DIRECTION OF THE MOTOR (ON) (POINT C)
DIP 2 TIMING (ON) (POINT D)
DIP 3 PAUSING TIME BEFORE AUTOMAtic closing in normal and
pedestrian mode (ON)
DIP 4 Jogging radio receiver (OFF) - automatic (ON)
DIP 5 Single impulse command (K BUTT) jogging (OFF) - automatic (ON)
Photocells always active (OFF) - Photocells active only on closure (ON)
DIP 6
DIP 7 Encoder for the PLUS model (ON - operated)
DIP 8 Pre-blinking (ON) - Normal blinking (OFF)
Slow speed - only in closing (ON-operated)
DIP 9
DIP 10 Electric Lock (ON-operated)
DIP 11 Release pulse in opening phase (ON- operated)
DIP 12 230V Motor (OFF) 120V (ON)
S1 => «PROG.» Programming button
S2 => Select operation with 1 or 2 motors (default closed track 2 motors)
S3 => Timed operation jumper (OFF) or electric limit switches (ON) (IF APPLIED)
TORQUE - ELECTRONIC TORQUE REGULATOR
The torque is regulated by rotating the Trimmer TORQUE, varying the output voltage of motor
ends,(when rotated clockwise, more torque Is transmitted to the motor).
Such torque Is automatically Included 3 seconds after the start of every operating cycle.
This allows the motor to have the maximum pickup when it starts.
SLOWING DOWN
Use DIP 9 to enable or disable further slowing down. This only takes place just before final
closing by a reduction of the motor voltage (low voltage with electronic clutch) and is directly
proportional to the value set by the electronic clutch trimmer.
LED SIGNALS
DL1 Photocell contact (NC)
DL2 M1 opening limit switch contact (NC)
DL3 M1 closing limit switch contact (NC)
DL4 M2 opening limit switch contact (NC)
DL5 M2 closing limit switch contact (NC)
DL6 Stop contact (NC)
DL7 M1 encoder operation control
DL8 M2 encoder operation control
DL9 Programming active
DL10 Closing gate M1
DL11 Closing gate M2
C - MOTOR DIRECTION OF ROTATION CONTROL
This control facilitates installation of the system and allows further checks to be performed.
1 - Release the motor and move the gate to half open position.;
2 - Put DIP1 in the ON mode => The LED DL9 starts blinking;
3 - Press the PROG button and hold it (the gate now is controlled in a dead man mode: open,
stop, close, stop, open) => THE RED LED DL10 and the DL11 come on and the gate
starts closing. The second leave closes four seconds after the first one. If this does not
happen, invert the wires of the motors V1,W1 and V2, W2);
4 - Press the PROG button and hold it => the gate starts opening. The two gate leaves will
open with a two second difference;
5 - Adjust the mechanical stoppers in opening;
6 - Press the hold the PROG button until both gate leaves reach the completely close position
and are now ready for the timing programming;
7 - Set the electrical limit switches if provided;
8 - At the end of the procedure, switch DIP1 to OFF. LED DL9 goes off to confirm exit from
the check procedure.
N.B. During this check, the encoder and photocells are not active.
D - TIME PROGRAMMING FOR TWO MOTORS (#)
THIS CAN BE DONE IN EITHER OF TWO WAYS:
MODE 1 - WITH ENCODER (DIP 7 ON AND JUMPER S3 OPEN)
- WITH ENCODER AND ELECTRIC LIMIT SWITCHES (IF APPLIED) (DIP 7 ON
AND JUMPER S3 CLOSED)
- WITHOUT ENCODER BUT WITH ELECTRIC LIMIT SWITCHES (IF APPLIED)
(DIP 7 OFF AND JUMPER S3 CLOSED)
MODE 2 - TIMED (DIP 7 OFF AND JUMPER S3 OPEN)
MODE 1
1 - Start with the gate completely closed and with mechanical stopper already regulated
like fig.10.
2 - Put DIP 2 in the ON mode => LED DL9 will blink rapidly.
3 - Press PROG. => M1 opens.
4 - When the gate comes into contact with the opening stop, the ENCODER stops M1 (with
storage of the encoder readings and the time) and M2 starts to open simultaneously.
5 - When the gate comes into contact with the opening stop, the ENCODER stops M1
(with storage of the encoder readings and the time) => the delay countdown prior to
automatic closing starts simultaneously (max 5 minutes).
6 - Press PROG. => delay countdown prior to automatic closing stops and M2 closes.
7 - Press PROG. => M1 closes and creates a phase difference between M2 and M1. At the
same time LED DL9 stops blinking to signal exit from the programming mode. At this
point, the safety devices and other gate controls will resume normal operation (inversions,
stops, alarms, etc.).
9 - The gate will stop at the end of the ENCODER countdown.
10 - AFTER PROGRAMMING, SWITCH DIP 2 TO OFF.
NOTE: The same procedure applies to electric limit switches (S3 closed). With S3 closed,
gate travel is determined by the electric limit switches and not by the encoder, which
only acts as a safety device.
MODE 2
1 - Start with the gate completely closed.
2 - Put DIP 2 in the ON mode => LED DL9 will blink rapidly.
3 - Press PROG. => M1 opens.
4 - When the gate comes into contact with the opening stop, wait one second and then press
PROG => M1 stops and M2 opens.
5 - When the gate comes into contact with the opening stop, wait one second and then
press PROG => M2 stops and the delay countdown prior to automatic closing starts
simultaneously (max 5 minutes).
6 - Press PROG. => delay countdown prior to automatic closing stops and M2 closes.
7 - Press PROG. => M1 closes and creates a phase difference between M2 and M1. At the
same time LED DL9 stops blinking to signal exit from the programming mode. At this
point, the safety devices and other gate controls will resume normal operation (inversions,
stops, alarms, etc.).
8 - The gate will stop at the end of the ENCODER countdown.
9 - AFTER PROGRAMMING, SWITCH DIP 2 TO OFF.
TIME PROGRAMMING FOR ONE MOTOR (#)
IMPORTANT: CUT OUT S2 TO OPERATE ONE MOTOR.
THIS CAN BE DONE IN EITHER OF TWO WAYS
MODE 3 - WITH ENCODER ONLY (DIP 7 ON AND JUMPER S3 OPEN)
- WITH ENCODER AND ELECTRIC LIMIT SWITCHES (IF APPLIED) (DIP 7 ON
AND JUMPER S3 CLOSED)
- WITHOUT ENCODER BUT WITH ELECTRIC LIMIT SWITCHES (IF APPLIED)
(DIP 7 OFF AND JUMPER S3 CLOSED)
MODE 4 - TIMED (DIP 7 OFF AND JUMPER S3 OPEN)
MODE 3
1 - Start with the gate completely closed and with mechanical stopper already regulated
like fig.10.
2 - Put DIP 2 in the ON mode => LED DL9 will blink rapidly.
3 - Press PROG. => M1 opens.
4 - When the gate comes into contact with the opening stop, the ENCODER stops M1 (with
storage of the encoder readings and the time) and the delay countdown priot to automatic
closing starts (max 5 minutes).
5 - Press PROG. => delay countdown prior to automatic closing stops and M2 closes. At
the same time LED DL9 stops blinking to signal exit from the programming mode. At this
point, the safety devices and other gate controls will resume normal operation (inversions,
stops, alarms, etc.).
6 - The gate will stop at the end of the ENCODER countdown.
7 - AFTER PROGRAMMING, SWITCH DIP 2 TO OFF.
NOTE: The same procedure applies to electric limit switches (S3 closed). With S3 closed,
gate travel is determined by the electric limit switches and not by the encoder, which
only acts as a safety device.
